| Characteristics |
Operating System |
Safedroid OS (Based on Android 4.3) |
| CPU |
Quad core 1.2GHz |
| Display |
3.5inch TFT-LCD VGA (480×640) color touch screen |
| Panel |
Resistive screen |
| RAM |
1GB |
| ROM |
8GB |
| Extended Memory |
Micro SD slot, up to 32 GB |
| Physical Characteristics |
Dimensions (LxWxD) |
192mm×73.8mm×29mm |
| Weight |
385g (includes battery) |
| Keyboard |
32keys; Number/Alphabetic keys; Directional button; Scan button; Side keypad |
| Input |
Chinese, English, handwriting, support soft keyboard |
| Promting Mode |
Green, red and blue LED, vibration, speaker |
| Barcode Scanner |
1D Laser |
Code 39; Codabar; Code 128;Discrete 2 of 5; IATA 2 of 5; Interleaved 2 of 5; Code 93; UPC A; UPC E0; EAN 8; EAN 13;MSI; EAN 128; UPC E1; Trioptic Code 39; Bookland EAN;Coupon Code; RSS-Limited; RSS-14; RSS-Expanded; |
| 2D Imager Scanner(Optional) |
1D Symbologies: UPC/EAN, Bookland EAN, UCC Coupon Code, ESSN EAN,CODE 39, CODE 128,GS1-128, ISBT 128, Trioptic Code 39, CODABAR, MSI, Interleaved 2/5, Discrete 2/5, Chinese2/5 ,Korean3/5, Matrix 2/5, 2D Symbologies: PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse, MaxiCode, QR Code, Aztec, Aztec InverseCODE 32, CODE 93, CODE 11, Inverse 1D, GS1 DataBar, Composite CodesPostal Codes:U.S. Postnet, U.S. Planet, U.K. Postal, Japan Postal, Australian Postal, Netherlands KIX Code,USPS 4CB/One Code/Intelligent Mail, UPU FICS Postal |
| Radio Communication |
WiFi |
WiFi 802.11 b/g/n; 802.1X(EAP, PEAP and LEAP) |
| Bluetooth |
Bluetooth 4.0 HS low energy |
| WCDMA |
GSM:850/900/1800/1900 MHz |
| UMTS/HSPA+: 850/900/1900/2100 MHz |
| Power |
Main Battery |
Removable, rechargeable 3.8V 4500mAh lithium battery pack |
| Slave Battery |
290mAh lithium battery |
| RTC Battery |
For real time clock keeping |
| Adapter |
5.5V / 2.6A |
| Options |
Camera |
5.0 mega pixels camera with flash, screen capture and automatic focus |
| GPS |
Support A-GPS |
| RFID(optional) |
HF: Supports 13.56Mhz, ISO14443A/B and ISO15693 standard, Not compatible with pistol grip |
| UHF:840-960MHZ EPC Frequency Band; support ISO18000-6B, ISO18000-6C (EPC Global Class1 Gen2) |
| Read and write distance: 2 meters; Read Speed: 200times/s (Read 200 tags in one second) |
| User Environment |
Operating Temp |
0℃ to +50℃ |
| Storage Temp |
-20℃ to +70℃ |
| Humidity |
5% to 95% non-condensing (Condensation Resistant Configurations Available) |
| Sealing |
IP65 |
| Drop Grade |
1.5m |
| Roller Drop Test |
500 times (1000 hits) |
| Peripherals and Accessories |
Expansion |
Micro SD/TF×1 (a maximum of 32 GB), Micro SIM×1, SAM×2 |
| Interfaces |
Micro USB×1, POGO PIN×1, 3.5mm Audio Jack×1 |
| Grip |
Optional |
| Stylus |
Optional |
| Cradle(Optional) |
Supports to charge one unit of device and one spare battery simultaneously |
| Input: AC 100V~240V, 1A Max,50/60Hz; Output: DC 5.5V, 2.6A; Two indicator LED: Power and Status |
| Regulatory |
Certification |
CCC, CE, ROHS |
| Warranty |
1 year factory warranty for main device; 3 months for accessories |
